Features

Parameter

  • Model
  • HL-HV1 series

  • Battery Type
  • LiFePO4

  • Module Range
  • 3-8

  • Capacity Range
  • 7.68-20.48kWh

  • Working Voltage Range
  • 136.8-460.8V

  • Maximum Continuous Charge/Discharge Current
  • 50

  • Power Control Unit Dimension
  • 550*380*230mm

  • Battery Module Dimension
  • 550*380*130mm

  • Weight (kg)
  • 104-244KG

  • Cycle life
  • 6000 cycles

  • Working temperature (℃)
  • Charging:0-45℃

    Discharging:-20-50℃

  • Communication Protocol
  • CAN/RS485

  • Protection rate
  • IP65

  • Certification
  • CE/UN38.3

  • Maximum Number In Parallel
  • 16
