| Basic Parameters | 3-Modules | 4-Modules | 5-Modules | 6-Modules | 7-Modules | 8-Modules |
| Model | ATOM HS-15.36 | ATOM HS-20.48 | ATOM HS-25.6 | ATOM HS-30.72 | ATOM HS-35.84 | ATOM HS-40.96 |
| Battery type | LiFePO4 | |||||
| Nominal voltage | 153.6V | 204.8V | 256.0V | 307.2V | 358.4V | 409.6V |
| Nominal capacity | 15.36kWh | 20.48kwh | 25.6kwh | 30.72kwh | 35.84kWh | 40.96kwh |
| Max charge and discharge current | 100A | |||||
| Max charge and discharge power | 15.36kW | 20.48kW | 25.6kW | 30.72kW | 35.84kW | 40.96kW |
| Communication | CAN/RS485/WIFI | |||||
| Weight | 182Kg | 232Kg | 282Kg | 332Kg | 382Kg | 432Kg |
| Dimensions(L*W） | 590*405mm | |||||
| Dimensions(H） | 675mm | 835mm | 995mm | 1155mm | 1315mm | 1475mm |
| Working temeprature range | charge0~45°C,discharge-20-55°C | |||||
| Efficiency | ≥97% | |||||
| Cycle life | 6000cycles | |||||
| Designed lifespan | ≥10 years | |||||
| Shell protection grade | IP65 | |||||
| Shell protection grade | C3+ class anti-corrosion | |||||
| Auxiliary heating function | Optional | |||||
| Parallel connection | suggest≤4 clusters | |||||
| Installation | floor standing | |||||
| Compatible inverter | Afore ,Growatt ,Solis , DEYE ,Pylon,Megarevo ,INVT, and customization | |||||
| Certification | CB-IEC62619,CE,UN38.3 | |||||
