| Basic Parameters | 3-Modules | 4-Modules | 5-Modules | 6-Modules | 7-Modules | 8-Modules | |||
| Model | ATOM HS-15.36 | ATOM HS-20.48 | ATOM HS-25.6 | ATOM HS-30.72 | ATOM HS-35.84 | ATOM HS-40.96 | |||
| Battery type | LiFePO4 | ||||||||
| Nominal voltage | 153.6V | 204.8V | 256.0V | 307.2V | 358.4V | 409.6V | |||
| Nominal capacity | 15.36kWh | 20.48kWh | 25.6kWh | 30.72kWh | 35.84kWh | 40.96kWh | |||
| Max charge and discharge current | 100A | ||||||||
| Max charge and discharge power | 15.36kW | 20.48kW | 25.6kW | 30.72kW | 35.84kW | 40.96kW | |||
| Communication | CAN/RS485/WIFI | ||||||||
| Weight | 182Kg | 232Kg | 282Kg | 332Kg | 382Kg | 432Kg | |||
| Dimensions（ L*W） | 590*405mm | ||||||||
| Dimensions（ H ） | 675mm | 835mm | 995mm | 1155mm | 1315mm | 1475mm | |||
| Working temeprature range | charge0~45℃ , discharge-20~55℃ | ||||||||
| Efficiency | ≥97% | ||||||||
| Cycle life | 6000cycles | ||||||||
| Designed lifespan | ≥10 years | ||||||||
| Shell protection grade | IP65 | ||||||||
| Shell protection grade | C3+ class anti-corrosion | ||||||||
| Auxiliary heating function | Optional 选配 | ||||||||
| Parallel connection | suggest ≤ 4 clusters | ||||||||
| Installation | floor standing | ||||||||
| Compatible inverter | Afore ,Growatt,Solis , DEYE ,Pylon,Megarevo,INVT, and customization | ||||||||
| Certification | CB-IEC62619,CE,UN38.3 | ||||||||
